    LiYY PVC Unscreened Flex Data Cables Stranded Copper Wire Gray Jacket

    Ask Lasest Price
    Brand Name : Zion communication OR OEM
    Model Number : Flex Data Transmission Cable
    Certification : CE, RoHS, VDE, UL
    Payment Terms : T/T, L/C
    Supply Ability : 1000KM / Month
    Delivery Time : 25 working days
    • Product Details
    • Company Profile

    LiYY PVC Unscreened Flex Data Cables Stranded Copper Wire Gray Jacket

    LiYY PVC Unscreened Flex Data Cables Stranded Copper Wire Gray Jacket

    Industrial Ethernet Cable

    https://www.zion-communication.com/Industrial-Ethernet-Cable-pl569518.html

    LiYY PVC unscreened flex data cables
    LiYY PVC Unscreened Flex Data Cables Stranded Copper Wire Gray Jacket
    ▉ Application
    These cables are used for flexible use with free movement without tensile stress or forced movements in dry, moist and wet rooms but not suitable for open air, wherever the construction requirements call for a minimum outer diameter, This applies especially to such areas as tool making and machine industries as well as electronic, computer, measurement and control sectors.
    ▉ Cable data
    flexible, color coded to DIN 47100
    Special PVC data cables, adapted to DIN VDE 0245, 0812
    Temperature range flexing -5°C to +80°C fixed installation -40°C to +80°C
    Nominal voltage 0,14 mm⊃2; == 350 V · 0,25 mm⊃2; = 500 V
    Test voltage up to 0,25 mm⊃2; 1200 V from 0,34 mm⊃2; 2000 V
    Breakdown voltage up to 0,25 mm⊃2; 2400 V from 0,34 mm⊃2; 4000 V •
    Insulation resistance min. 20 MOhm x km
    Capacitance (approx.-value) at 800 Hz
    0,14 mm⊃2; 120 pF/m 0,25 mm⊃2; 150 pF/m
    Inductance approx. 0,65 mH/km
    Impedance approx. 78 Ohm
    Minimum bending radius flexing 7,5x cable Ø fixed installation 4x cable Ø
    ▉ Cross Section
    LiYY PVC Unscreened Flex Data Cables Stranded Copper Wire Gray Jacket
    ▉ Product List
    Item No. Description&No.Conductors xcross-sec mm⊃2; Outer
    Diameter    		 Weight ca
    kg/km
    7132000 2X0.14 3.2 13.0
    7132001 3X0.14 3.2 16.0
    7132002 4X0.14 3.5 19.0
    7132003 5X0.14 4.0 22.0
    7132004 6X0.14 4.3 25.0
    7132005 7X0.14 4.3 28.0
    7132006 8X0.14 4.6 35.0
    7132007 10X0.14 5.3 41.0
    7132008 12X0.14 5.6 48.0
    7132009 14X0.14 5.9 53.0
    7132010 16X0.14 6.2 59.0
    7132011 18X0.14 6.5 65.0
    7132012 20X0.14 6.5 70.0
    7132013 21X0.14 6.8 77.0
    7132014 24X0.14 7.6 87.0
    7132015 25X0.14 7.6 91.0
    7132016 27X0.14 7.7 97.0
    7132017 30X0.14 8.0 108.0
    7132018 32X0.14 8.2 114.0
    7132019 36X0.14 8.7 126.0
    7132020 40X0.14 9.5 139.0
    7132021 42X0.14 9.8 146.0
    7132022 44X0.14 10.3 153.0
    7132023 48X0.14 10.4 164.0
    7132030 2X0.25 3.8 18.0
    7132031 3X0.25 3.9 22.0
    7132032 4X0.25 4.3 26.0
    7132033 5X0.25 4.8 30.0
    7132034 6X0.25 5.2 36.0
    7132035 7X0.25 5.2 42.0
    7132036 8X0.25 5.7 49.0
    7132037 10X0.25 6.4 57.0
    7132038 12X0.25 6.7 66.0
    7132039 14X0.25 7.1 75.0
    7132040 16X0.25 7.5 84.0
    7132041 18X0.25 7.9 72.0
    7132042 19X0.25 8.4 84.0
    7132043 20X0.25 9.1 101.0
    ▉ Product List
    Item No. Description&No.Conductors xcross-sec mm⊃2; Outer
    Diameter    		 Weight ca
    kg/km
    7132044 21X0.25 9.3 107.0
    7132045 24X0.25 9.8 120.0
    7132046 25X0.25 9.9 132.0
    7132047 27X0.25 10.1 140.0
    7132048 30X0.25 10.3 156.0
    7132049 32X0.25 10.5 164.0
    7132050 36X0.25 11.1 182.0
    7132051 37X0.25 11.3 190.0
    7132052 40X0.25 11.5 200.0
    7132053 42X0.25 11.8 211.0
    7132054 44X0.25 12.6 225.0
    7132055 48X0.25 12.7 245.0
    7132060 2X0.34 4.2 22.0
    7132061 3X0.34 4.4 30.0
    7132062 4X0.34 4.9 43.0
    7132063 5X0.34 5.3 54.0
    7132064 6X0.34 5.8 58.0
    7132065 7X0.34 5.9 61.0
    7132066 8X0.34 6.3 73.0
    7132067 10X0.34 7.2 82.0
    7132068 12X0.34 7.6 102.0
    7132069 14X0.34 8.0 108.0
    7132070 16X0.34 8.4 126.0
    7132071 18X0.34 8.9 143.0
    7132072 20X0.34 9.8 160.0
    7132073 21X0.34 9.8 166.0
    7132074 24X0.34 11.0 186.0
    7132075 25X0.34 11.2 192.0
    7132076 27X0.34 11.2 206.0
    7132077 30X0.34 11.6 226.0
    7132078 32X0.34 11.9 245.0
    7132079 36X0.34 12.6 285.0
    7132080 37X0.34 12.9 292.0
    7132081 40X0.34 13.5 318.0
    7132082 42X0.34 14.0 330.0
    7132083 44X0.34 14.7 370.0
    7132084 48X0.34 14.9 405.0
    ▉ Product List
    7132090 2x0.5 4.8 40.0
    7132091 3x0.5 5.1 46.0
    ▉ Order Informations
    Marking HELLOSIGNAL Industrial LiYY PVC unscreened flex data cables XXXFT/M
    Package 100m/Reel, 300m/Wooden Spool
    Delivery time Normally 25 days after received the deposit.
    Brand HELLOSIGNAL® OR OEM
